HP Z2 Mini G9 — Intel Core i7, 14th Gen
32 GB DDR5-5600 (1 × 32 GB) RAM · 1 TB PCIe Gen4 NVMe M.2 SSD · NVIDIA T1000 (8 GB GDDR6) + Intel UHD Graphics 770 (integrated) · Intel Core i7-14700 (14th Gen) · 20 cores (8 P-cores + 12 E-cores) / 28 threads
Enquire about an HP Z2 Mini G9 compact workstation for your team in India. This configuration, HP product A2JZ9ES, pairs an Intel Core i7-14700 with 32 GB DDR5 memory, a 1 TB NVMe SSD and NVIDIA T1000 8 GB graphics. It is HP’s South Africa product; the supplied unit and its terms are confirmed in your quotation.
1 / 3
Is this the right desktop for your work?
CAD, engineering and technical software
A 20-core Core i7-14700 with an NVIDIA T1000 workstation card suits 2D CAD, engineering and moderate 3D work in very little desk space. Check your application vendor’s certified-hardware list; heavy rendering or large 3D assemblies may need a bigger card.
Desks, labs and behind-the-monitor installs
VESA mounting, a small footprint and remote management suit reception desks, labs, kiosks and hot desks. Plan the monitor and keyboard separately.
Multi-monitor and wired office setups
The motherboard’s two DisplayPort outputs plus the T1000’s own outputs support multi-monitor desks, with gigabit Ethernet and fast front USB-C. Validate your monitors, resolutions and cables before ordering.
Processor & graphics
HP offers the Z2 Mini G9 with Intel Core 12th, 13th and 14th Gen processors on the W680 workstation chipset, with integrated graphics or an optional discrete NVIDIA card. This configuration has the Core i7-14700 with an NVIDIA T1000.
Show 7 specificationsHide specifications
| Processor | Intel Core i7-14700 (14th Gen) HP configuration A2JZ9ES, the product the owner identified for this unit. HP product specifications — A2JZ9ESIntel — Core i7-14700 specifications |
|---|---|
| CPU | 20 cores (8 P-cores + 12 E-cores) / 28 threads HP product specifications — A2JZ9ESIntel — Core i7-14700 specifications |
| CPU clocks & power | Up to 5.4 GHz max turbo (5.3 GHz P-core, 4.2 GHz E-core); 65 W base power Max turbo is a single-core maximum, not a sustained all-core figure. Intel — Core i7-14700 specificationsHP product specifications — A2JZ9ES |
| CPU cache | 33 MB Intel Smart Cache HP product specifications — A2JZ9ESIntel — Core i7-14700 specifications |
| Chipset | Intel W680 (LGA1700 socket) HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Graphics | NVIDIA T1000 (8 GB GDDR6) + Intel UHD Graphics 770 (integrated) Discrete low-profile workstation card in the PCIe slot, with the processor’s integrated graphics. HP product specifications — A2JZ9ESHP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Other factory graphics options | NVIDIA T400, T400E, RTX A400, T1000 (4 or 8 GB), RTX A1000, RTX 2000 Ada, RTX A2000 12 GB or RTX 4000 SFF Ada Factory options on the model; this configuration has the T1000. A discrete card needs HP’s Performance Base Unit (PCIe Gen4 x8 riser) and the 280 W adapter. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
Memory & upgrades
HP documents removable SODIMM memory and two M.2 SSD slots, with tool-less access to the memory. Supported upgrades do not establish what is installed in a particular unit.
Show 5 specificationsHide specifications
| Installed memory | 32 GB DDR5-5600 (1 × 32 GB) One of the two SODIMM slots is free. QuickSpecs lists dual-rank 32 GB modules at 5200 MT/s with 14th Gen processors. HP product specifications — A2JZ9ES |
|---|---|
| Documented memory rate | DDR5 up to 5600 MT/s: 5600 MT/s with single-rank 8 or 16 GB modules, 5200 MT/s with dual-rank 32 GB modules (14th Gen) HP’s US configurations list their 1 × 32 GB module as DDR5-5600, and the service guide (written before the 5600 modules) lists DDR5-4800; the page follows the QuickSpecs speed table. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| RAM slots & upgrades | 2 removable DDR5 SODIMM slots (one per channel), up to 64 GB; ECC or non-ECC, not mixed Memory access is tool-less. This configuration uses 1 × 32 GB, leaving one slot free for a second module. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PCHP Maintenance and Service Guide — Z2 Mini G9 |
| Installed storage | 1 TB PCIe Gen4 NVMe M.2 SSD The second M.2 2280 slot is free. HP product specifications — A2JZ9ES |
| SSD slots & upgrades | 2 × M.2 2280 PCIe Gen4 x4 NVMe slots; no SATA or 2.5-inch drive bay NVMe RAID 0/1 is supported. HP factory drives range from 256 GB to 4 TB. Replacing or adding an M.2 drive needs a screwdriver. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PCHP Maintenance and Service Guide — Z2 Mini G9 |
Size & mounting
The Z2 Mini is HP’s mini workstation form factor: it sits on a desk, stands vertically or mounts behind a monitor. Keyboard, mouse and display are separate quote items.
Show 5 specificationsHide specifications
| Form factor | Mini workstation desktop with external power adapter HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PCHP Maintenance and Service Guide — Z2 Mini G9 |
|---|---|
| Width × depth × height | 211 × 218 × 69 mm HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Weight | 2.4 kg to 3.1 kg, depending on configuration HP’s minimum and maximum configured weights; not a measurement of a supplied unit. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Mounting | Integrated VESA mounting holes; optional VESA arm/wall mount, vertical stand, rail rack kit and mounting brackets Mounts and stands are sold separately; confirm any accessory in the quotation. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Service access | Tool-less access panel and memory; M.2 drives and expansion cards need a screwdriver HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PCHP Maintenance and Service Guide — Z2 Mini G9 |
Power supply
The Z2 Mini uses an external power adapter; the wattage depends on the processor and graphics fitted.
Show 1 specificationsHide specifications
| Power supply | 280 W external adapter, up to 90% efficiency, active PFC HP’s configuration for A2JZ9ES. The model also has a 180 W adapter, which cannot power a discrete card. Confirm the adapter and plug supplied with the unit. HP product specifications — A2JZ9ESHP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
|---|
Ports & networking
USB and audio sit on the front panel (HP calls it the side), displays and networking on the rear. One rear bay takes an optional Flex IO module, so a supplied unit may have an extra port there.
Show 5 specificationsHide specifications
| Front ports | 1 × USB-A 10 Gbps (charging), 2 × USB-C 20 Gbps (charging), 1 × universal audio jack A port’s advertised maximum is not measured throughput. USB-C charging is 5 V / 3 A for devices, not laptop power delivery. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
|---|---|
| Rear ports | 2 × DisplayPort 1.4, 1 × RJ45 Ethernet, 3 × USB-A 10 Gbps, plus one optional Flex IO module HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Flex IO module options | One of: VGA, HDMI 2.0b, DisplayPort 1.4, dual USB-A 5 Gbps, USB-C 10 Gbps with DisplayPort, 1 GbE, 2.5 GbE, 10 GbE, fibre 1 GbE, serial, or Thunderbolt 3 with USB4 40 Gbps Factory options. Which module, if any, is fitted is confirmed on the supplied unit. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Display outputs | 2 × DisplayPort 1.4 on the rear; up to 3 displays A video Flex IO module or a discrete graphics card adds outputs. Validate your monitors and resolutions before ordering. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Networking | 1 GbE Intel I219-LM Ethernet; optional Intel Wi-Fi 6E AX211 + Bluetooth 5.3 or Wi-Fi 7 BE200 + Bluetooth 5.4 HP fits wireless at the factory only. Confirm whether the supplied unit has Wi-Fi. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
Software & security
Operating system, security and remote management are workstation features; confirm the installed edition and licence on the supplied unit.
Show 4 specificationsHide specifications
| Operating system | Factory options: Windows 11 Pro or Home, Windows 11 Pro with Windows 10 Pro downgrade rights, or Ubuntu/Linux-ready HP also lists Red Hat Enterprise Linux 8/9 and SLED 15 as supported. Confirm the installed edition, version and licence. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
|---|---|
| Security | TPM 2.0 (Infineon SLB 9670), HP Sure Start Gen7, security lock slot, optional hood sensor HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Remote management | Intel vPro with AMT 16 through the Intel I219-LM Ethernet controller vPro depends on the processor fitted; the photographed unit carries an Intel vPro i7 badge. HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
| Audio | Realtek ALC3205 audio with a 2 W internal mono speaker HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PC |
Confirm the desktop. Then confirm the terms.
- The owner supplied “HP Z2 Mini G8, i7 14th Gen, 32 GB DDR5, 1 TB NVMe” and identified the product as HP A2JZ9ES. HP never made a Z2 Mini G8; A2JZ9ES is a Z2 Mini G9, so this page covers the G9.
- A2JZ9ES is HP’s South Africa product; it does not establish Indian availability. Confirm the supplied unit, its condition and terms in the quotation.
- Confirm the power adapter and plug, Windows licence and any Wi-Fi on the supplied unit; HP’s specification for A2JZ9ES lists no wireless module.
- HP’s configuration lists an HP Wired 320M mouse; monitor, keyboard and mounting accessories are separate items. List what you need in your enquiry.
- Share quantity, workload, city and required date. Confirm availability, price, GST, delivery charges and warranty provider, duration and exclusions.
Related options: Rental product categoriesAvailable productsContact SPURGERead our sales terms.
HP Z2 Mini G9 FAQs
Is this the Z2 Mini G8 or G9?
The G9. HP’s Z2 Mini line has no G8: HP sold a Z2 G8 as a tower and small form factor, and the mini moved from G5 to G9. Core i7 14th Gen processors with DDR5 memory are offered only on the Z2 Mini G9.
HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PCHP Maintenance and Service Guide — Z2 Mini G9Can the memory and storage be upgraded?
Yes. HP documents two removable DDR5 SODIMM slots up to 64 GB and two M.2 2280 PCIe Gen4 NVMe slots. This configuration uses one 32 GB module and one M.2 slot, so both a second memory module and a second SSD can be added.
HP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PCHP Maintenance and Service Guide — Z2 Mini G9Does it have a graphics card?
Yes. HP configuration A2JZ9ES has an NVIDIA T1000 with 8 GB GDDR6 alongside the processor’s Intel UHD Graphics 770, powered by the 280 W adapter. HP offers larger cards up to the RTX 4000 SFF Ada as factory options on this model.
HP product specifications — A2JZ9ESHP QuickSpecs — HP Z2 Mini G9 Workstation Desktop PCDoes it come with a monitor, keyboard and mouse?
HP’s configuration for A2JZ9ES lists an HP Wired 320M mouse; the display, keyboard and any mount are separate. Include what you need in your enquiry and SPURGE confirms the accessories with the quote.
HP product specifications — A2JZ9ESHow do I request this workstation from SPURGE?
Send the specification, quantity, city and required date. SPURGE confirms the exact unit — including the power adapter, accessories and OS licence — and quotes rental or purchase terms before an order.
Check the facts at the source.
- QuickSpecs — HP Z2 G9 Mini Workstation Desktop PC (c08109685, DA-17010, Worldwide, Version 42, September 1, 2025)
Worldwide model specification: processors, chipset, graphics, memory, storage, ports, Flex IO, wireless, power adapters, size, weight, mounting, OS and security. HP notes not all components are available in all regions; it lists options, not complete factory configurations. Checked .
- Maintenance and Service Guide — HP Z2 Mini G9 Workstation Desktop PC (First Edition April 2022; Third Edition August 2024; N02514-003)
Components, memory and M.2 SSD removal procedures and spare parts for the model; global. Checked .
- Intel Core i7-14700 Processor (33M Cache, up to 5.40 GHz) — specifications
Processor component facts: cores/threads, clocks, cache, power and integrated UHD Graphics 770. Processor memory limits are not used as workstation capabilities. Checked .
- HP Support product specifications — HP Z2 Mini G9, product number A2JZ9ES (South Africa)
HP’s own specification record for one complete configuration: Core i7-14700, 32 GB DDR5-5600 (1 × 32 GB), 1 TB PCIe Gen4 NVMe, NVIDIA T1000 8 GB, 280 W adapter, Windows 11 Pro, HP Wired 320M mouse. The owner identified this product for the unit. South Africa product; not evidence of Indian availability. Checked .
