Lenovo · 2020

Lenovo Legion 5 15IMH05

Configuration

10th Gen Intel Core i7-10750H · 16 GB DDR4-2933 (2 × 8 GB) · 256 GB M.2 2280 PCIe NVMe SSD

1 / 4

Price and availability confirmed on enquiry.

WhatsApp

Is this the right laptop for your work?

Enquire about a Lenovo Legion 5 15IMH05 gaming laptop for rent or purchase in India. This configuration has a 10th Gen Intel Core i7-10750H (6 cores), an NVIDIA GeForce GTX 1650 with 4 GB of GDDR6, 16 GB of DDR4 memory and a 256 GB NVMe SSD on a 15.6-inch Full HD 120 Hz display. SPURGE’s unit has the SSD only, leaving the 2.5-inch drive bay free; condition, battery health, price and rental terms are confirmed on enquiry.
  1. Entry-level gaming and esports titles

    A six-core i7-10750H with a GTX 1650 and a 120 Hz Full HD panel suits popular esports and older titles at moderate settings. Check the specific games you need before ordering.

  2. Students and creators learning on a GPU

    CUDA-capable NVIDIA graphics and 16 GB of dual-channel memory for photo editing, 1080p video editing, CAD coursework and introductory 3D work. Validate heavier projects against 4 GB of video memory.

  3. Desk setups with external monitors

    HDMI 2.0 and USB-C with DisplayPort drive up to two external displays alongside the laptop screen, with Ethernet and most ports on the rear panel to keep cables tidy.

Technical specifications

Processor & graphics

The 2020 Legion 5 15IMH05 (machine type 82AU) is Lenovo’s 15.6-inch gaming laptop on 10th Gen Intel Core H-series processors, with an NVIDIA GeForce GTX 1650 or GTX 1650 Ti alongside the processor’s Intel UHD Graphics.

Show 6 specifications
Lenovo Legion 5 15IMH05: Processor & graphics
Processor

10th Gen Intel Core i7-10750H

Lenovo India models 82AU00AXIN, 82AU00G8IN and 82AU00KKIN pair this processor with a GTX 1650 4 GB, 16 GB (2 × 8 GB) DDR4-2933, a 256 GB SSD plus a 1 TB hard drive, the 120 Hz panel and a 60 Wh battery.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo PSREF specifications — Legion 5 15IMH05Intel Core i7-10750H specifications
CPU

6 cores / 12 threads, 2.6 GHz base, up to 5.0 GHz

Intel ARK: 12 MB cache, 45 W base power (35 W configurable).

Intel Core i7-10750H specificationsLenovo PSREF specifications — Legion 5 15IMH05
Documented CPU options

10th Gen Intel Core i5-10300H or i7-10750H

Lenovo’s datasheet also names the i7-10875H as “tech ready”, but no 82AU model in Lenovo’s product reference ships with it.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo PSREF — Legion 5 15IMH05 models
Graphics

NVIDIA GeForce GTX 1650 (4 GB GDDR6) + Intel UHD Graphics

Lenovo lists GDDR6 for this model. Windows shows both adapters; the integrated graphics use shared system memory.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo PSREF specifications — Legion 5 15IMH05
Graphics power (TGP)

Not published by Lenovo for this model

Not published

NVIDIA’s original GTX 1650 laptop page gave a 35–50 W range for the GDDR5 version; that is not a Lenovo figure for this laptop.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5i (15") datasheetLenovo Legion 5 (15″, 05) User GuideLenovo Legion 5 Hardware Maintenance Manual
External displays

Up to three independent displays (laptop screen, HDMI and USB-C); HDMI up to 4096 × 2160 at 60 Hz, USB-C up to 3840 × 2160 at 60 Hz

Lenovo PSREF specifications — Legion 5 15IMH05
Technical specifications

Memory & upgrades

Memory sits in two SO-DIMM slots with nothing soldered. India models pair one M.2 NVMe SSD slot with a 2.5-inch drive bay; Lenovo lists memory and drives as service parts rather than customer-replaceable ones.

Show 5 specifications
Lenovo Legion 5 15IMH05: Memory & upgrades
Installed memory

16 GB DDR4-2933 (2 × 8 GB)

Every 16 GB factory 82AU model uses two 8 GB modules, so both slots are filled. Confirm the modules in the supplied unit.

Lenovo PSREF — Legion 5 15IMH05 models
Documented memory speed

DDR4-2933, dual-channel capable

Lenovo notes the installed modules are 3200 MHz parts running at 2933 MHz, the processor’s limit.

Lenovo PSREF specifications — Legion 5 15IMH05
RAM slots & upgrades

Two DDR4 SO-DIMM slots, none soldered; Lenovo lists up to 16 GB from its own offerings

Lenovo says the laptop “may support more memory” than the 16 GB it offered, and publishes no per-slot limit. A 16 GB factory configuration fills both slots with 8 GB modules. Memory is a service (FRU) part, not a customer-replaceable unit.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5 (15″, 05) User GuideLenovo Legion 5 Hardware Maintenance Manual
Installed storage

256 GB M.2 2280 PCIe NVMe SSD

SPURGE’s supplied unit has this SSD only, with no hard drive (owner confirmation, 2026-10-06). Lenovo India’s matching factory models paired the 256 GB SSD with a 1 TB 5400 rpm hard drive; Lenovo India also sold 82AU custom builds with a 256 GB SSD and no hard drive.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo India — Legion 5i 15 build-your-own (archived 2021)
Drive slots & upgrades

India models: one M.2 2280 PCIe 3.0 x4 NVMe slot (also takes 2242) and one 2.5-inch 7 mm SATA bay; other builds have two M.2 slots instead

Lenovo lists tested limits of 1 TB for an M.2 2280 SSD, 512 GB for M.2 2242 and 2 TB for a 2.5-inch hard drive. The 2.5-inch bay is empty in SPURGE’s supplied unit.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo PSREF — Legion 5 15IMH05 modelsLenovo Legion 5 (15″, 05) User Guide
Technical specifications

Display & size

A 15.6-inch Full HD anti-glare IPS display in a Phantom Black chassis 363 mm wide and up to 26.1 mm thick, starting at 2.3 kg.

Show 4 specifications
Lenovo Legion 5 15IMH05: Display & size
Display diagonal

15.6 inches

Lenovo PSREF specifications — Legion 5 15IMH05
Display

1920 × 1080 Full HD IPS, anti-glare, non-touch, 250 nits, 120 Hz, 45% NTSC

This is the panel in every Lenovo India 82AU model. Other markets also had 144 Hz and 60 Hz 300-nit 100% sRGB panels. Confirm the supplied unit’s panel.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo PSREF specifications — Legion 5 15IMH05
Width × depth × height

363.06 × 259.61 × 23.57–26.1 mm

The User Guide rounds the depth to 260 mm.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5i (15") datasheet
Model weight

Starting at 2.3 kg

Varies with configuration; a hard drive adds weight. Lenovo’s launch press release gave 2.5 kg for the wider Legion 5i range, which includes RTX models.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5i (15") datasheet
Technical specifications

Battery & charging

A 60 Wh battery in every Lenovo India 82AU model, charged through a 170 W slim-tip adapter at the rear.

Show 4 specifications
Lenovo Legion 5 15IMH05: Battery & charging
Battery capacity

60 Wh 4-cell lithium-polymer, integrated

An 80 Wh battery was offered in other markets. Confirm the battery health of the supplied unit.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo PSREF specifications — Legion 5 15IMH05
Published battery runtime

Up to about 5.9 hours with the 60 Wh battery (MobileMark 2018)

A benchmark maximum that varies with settings and use; gaming on the GTX 1650 runs the battery down far sooner. A renewed unit needs its own battery-health check.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5i (15") datasheet
Charging

Rapid Charge Pro: up to 50% in 30 minutes, as Lenovo lists it

Lenovo does not state the test conditions on the specification sheet.

Lenovo PSREF specifications — Legion 5 15IMH05
Documented power adapter

170 W slim-tip adapter (rear power connector)

Every 82AU model lists 170 W. The family User Guide also lists 135 W and 230 W adapters for other Legion 5 models. Lenovo lists no USB-C charging. Confirm the supplied adapter.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo PSREF specifications — Legion 5 15IMH05
Technical specifications

Ports & wireless

Four USB-A ports, USB-C with DisplayPort, HDMI 2.0 and Gigabit Ethernet, most of them on the rear panel, with Wi-Fi 6.

Show 3 specifications
Lenovo Legion 5 15IMH05: Ports & wireless
USB ports

4 × USB-A 3.2 Gen 1 (5 Gbps; one always-on) — one left, one right, two rear; 1 × USB-C 3.2 Gen 1 (rear) with DisplayPort 1.2

Lenovo lists the USB-C port for data and DisplayPort only, without charging. There is no Thunderbolt.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5 (15″, 05) User Guide
Other connections

1 × HDMI 2.0; RJ-45 Gigabit Ethernet; 3.5 mm headphone/microphone combo jack; Novo button; Kensington Mini security slot

No memory card reader on the 15-inch model.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5 (15″, 05) User Guide
Wireless

Wi-Fi 6 (802.11ax) 2×2 with Bluetooth 5.0

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo PSREF — Legion 5 15IMH05 models
Technical specifications

Camera & everyday use

A 720p webcam with a sliding privacy shutter, dual microphones and Harman speakers with Dolby Atmos, above a full-size backlit keyboard with a numeric keypad.

Show 5 specifications
Lenovo Legion 5 15IMH05: Camera & everyday use
Camera

HD 720p, fixed focus, with a physical privacy shutter

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5 (15″, 05) User Guide
Speakers & microphone

Two 2 W Harman speakers with Dolby Atmos; dual-array microphones

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo Legion 5i (15") datasheet
Keyboard & touchpad

Six-row keyboard with numeric keypad and white backlight; buttonless multi-touch touchpad

White backlighting is listed for every Lenovo India 82AU model; a four-zone RGB keyboard was offered elsewhere. There is no fingerprint reader.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo PSREF specifications — Legion 5 15IMH05
Security chip

Firmware TPM 2.0

Lenovo PSREF specifications — Legion 5 15IMH05
Operating system

Windows 10 Home 64-bit in Lenovo India’s matching models

The photographed unit runs Windows 11. Confirm the installed edition, version and licence on the supplied unit.

Lenovo PSREF — Legion 5 15IMH05 models

Confirm the laptop. Then confirm the terms.

  • The processor, graphics and memory match Lenovo India models 82AU00AXIN, 82AU00G8IN and 82AU00KKIN, which also had a 1 TB hard drive; SPURGE’s unit has the 256 GB SSD only. These are Lenovo listings, not a SPURGE stock record. Availability, condition, price, GST, delivery and warranty are confirmed in the SPURGE quotation.
  • Lenovo’s support for this model ended on 27 May 2026, so new BIOS and driver releases should not be expected; ask about the warranty offered with the unit.
  • Both memory slots are filled with 8 GB modules in a 16 GB unit; a memory upgrade replaces modules. The 2.5-inch bay can take an extra SATA drive where it is empty.
  • The 170 W adapter is needed for full performance; Lenovo lists no USB-C charging. Ask for a battery-health report on a renewed unit.
  • Share quantity, workload, city and required date so SPURGE can confirm supply and quote rental or purchase terms.

Related options: Laptop rentals IndiaRefurbished laptopsNew laptop procurementContact SPURGERead our sales terms.

Lenovo Legion 5 15IMH05 FAQs

What graphics does the Legion 5 15IMH05 have?

This configuration has an NVIDIA GeForce GTX 1650 with 4 GB of GDDR6 memory, plus the processor’s integrated Intel UHD Graphics, which Windows lists as a second adapter. Lenovo does not publish the GTX 1650’s power limit for this model.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo PSREF — Legion 5 15IMH05 models

Can the RAM be upgraded?

The memory is in two SO-DIMM slots with nothing soldered. Lenovo lists up to 16 GB from its own offerings and says the laptop may support more, without publishing a per-slot limit. A 16 GB unit already fills both slots with 8 GB modules, so an upgrade means replacing them; SPURGE confirms the modules in the supplied unit.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo PSREF — Legion 5 15IMH05 modelsLenovo Legion 5 Hardware Maintenance Manual

Is there room for a second drive?

Yes. Lenovo India models have one M.2 2280 PCIe NVMe SSD slot and a 2.5-inch SATA bay. SPURGE’s unit has a 256 GB SSD and an empty bay, so a 2.5-inch SSD or hard drive can be added. Lenovo lists tested limits of 1 TB for the M.2 SSD and 2 TB for a 2.5-inch drive.

Lenovo PSREF specifications — Legion 5 15IMH05Lenovo PSREF — Legion 5 15IMH05 modelsLenovo Legion 5 (15″, 05) User Guide

Is this the same as the Legion 5 15IMH05H?

No. The Legion 5 15IMH05 is machine type 82AU, with GTX 1650 or GTX 1650 Ti graphics. The similarly named 15IMH05H is a separate model sold under machine types 81Y6 and 82CF, so its specifications do not apply here. Check the machine type on the bottom label.

Lenovo PSREF — Legion 5 15IMH05 modelsLenovo Support — Legion 5-15IMH05 (82AU)Lenovo Legion 5 Hardware Maintenance Manual

How do I request this laptop from SPURGE?

Send the specification, quantity, city and required date. SPURGE confirms the exact unit — including the memory modules, battery health, adapter and OS licence — and quotes rental or purchase terms before an order.

Check the facts at the source.

Configuration checked . Page updated . Each source has its own checked date below. Manufacturer specifications describe the model; a SPURGE quotation confirms the supplied device and terms.
  1. Lenovo PSREF product page “Lenovo Legion 5 15IMH05” with its Models list (machine type 82AU)

    Lenovo’s official product reference: 779 factory models, all machine type 82AU, 47 of them for India. India models 82AU00AXIN (2020-05-29), 82AU00G8IN (2020-07-09) and 82AU00KKIN (2020-08-25): i7-10750H / GTX 1650 4 GB GDDR6 / 2 × 8 GB DDR4-2933 / 256 GB M.2 2280 PCIe NVMe SSD + 1 TB 5400 rpm HDD / 15.6" FHD IPS 250 nits 120 Hz 45% NTSC / 60 Wh / white backlit keyboard / Wi-Fi 6 + BT 5.0 / Windows 10 Home / 170 W. Every 16 GB model uses 2 × 8 GB; no model pairs this CPU, GPU and memory with a 256 GB SSD alone. Data version 2026-09-30; product withdrawn. Checked .

  2. PSREF “Lenovo Legion 5 15IMH05” specifications PDF (March 31 2022), 7 pages

    Model-wide specifications: processors, graphics, chipset, memory and monitor support (p. 2); storage (pp. 2–3); audio, camera, battery, adapter (p. 3); display, keyboard, mechanical (p. 4); ports, wireless and security (p. 5). Checked .

  3. PSREF datasheet “Lenovo Legion 5i Laptop (15")”, specification block “Lenovo Legion 5 15IMH-05” (2020)

    Two-page datasheet: dimensions, starting weight 2.3 kg, MobileMark 2018 runtime note, 2 × 2 W Harman Kardon speakers (p. 2). Checked .

  4. User Guide — Lenovo Legion 5 (15″, 05) and Lenovo Legion 5 (17″, 05), First Edition (August 2020)

    Family guide covering 82AU and other types: port locations (PDF pp. 10–13), specifications including two memory slots, 7 mm 2.5-inch drive and dimensions (pp. 15–16), CRU list (p. 34). Adapter list covers the whole family. Checked .

  5. Hardware Maintenance Manual — Lenovo Legion 5 (15″, 05) and Lenovo Legion 5P (15″, 05), v1.1 (First Edition March 2020)

    Machine types including 82AU; CRU list (PDF p. 28); drive and memory module removal (PDF pp. 38–44). Checked .

  6. Lenovo India “Legion 5i (15)” build-your-own page 82AUCTO1WWENIN0, Wayback Machine capture of 2021-03-29

    Archived official India configure-to-order page. Base build: i5-10300H / 8 GB / GTX 1650 4 GB GDDR6 / 256 GB M.2 2280 SSD with “Hard Drive: None” / 15.6" FHD 60 Hz 300 nits / 60 Wh. The option list loads by script and was not captured, so whether an i7 with 16 GB could be chosen is unverified. Checked .

  7. Intel ARK — Intel Core i7-10750H Processor (12M Cache, up to 5.00 GHz)

    Processor facts only: launched Q2 2020, 6 cores / 12 threads, 2.60 GHz base, up to 5.00 GHz, 12 MB cache, 45 W (35 W configurable TDP-down), DDR4-2933, Intel UHD Graphics. Checked .

  8. Legion 5-15IMH05 (Lenovo) - Type 82AU | Lenovo PC Support

    Stable model-specific support page for drivers, BIOS and manuals; names the product “Legion 5-15IMH05 (Lenovo) - Type 82AU” and lists 82AU00AXIN, 82AU00G8IN and 82AU00KKIN as models. Checked .
